PF-3 Soil

Compact photometer for Soil applications

Compact Photometer

PF-3 Soil

The PF-3 soil photometer is part of the smallest member of the MACHEREY-NAGEL photometer family, providing a really handy way of carrying out site measurements.

It is simple and intuitive to use with just four buttons. Strong enough to resist the rigours of site work with shock resistant optics, reinforced housing and IP 68 rating.

Monitoring and reliable analysis is a cornerstone in supporting and maintaining healthy, productive and biologically active soil. To effectively and efficiently plan all measures that affect the soil (fertilization, liming, etc.), it is crucial to determine the important soil parameters (Nitrate, Phosphate, Potassium and Ammonium).

The PF-3 Soil in combination with the proven VISOCOLOR® ECO Test kits and NANOCOLOR® tests are ideally suited for mobile analysis of the soil quality right at the point of interest.

soil analysis

Tests for use with PF-3 Soil:

VISOCOLOR ECO

  • Ammonium 3 : 0.2-4.0 mg/kg NH4-N REF: 931 208
  • Potassium : 40-300 mg/kg K REF: 931 232
  • Nitrate : 2-28 mg/kg NO3-N REF: 931 241
  • Phosphate : 20-500 mg/kg PO4-P REF: 931 284

NANOCOLOR

  • Ammonium 3 : 0.08-4.60 mg/kg NH4-N REF: 985 003
  • Ammonium 10 : 0.4-16.0 mg/kg NH4-N REF: 985 004
  • Ammonium 50 : 2.0-80.0 mg/kg NH4-N REF: 985 005
  • Nitrate 50 : 1-44 mg/kg NO3-N REF: 985 064
  • Phosphate 5 : 4-100 mg/kg PO4-P REF: 985 081
  • Phosphate 15 : 6-300 mg/kg PO4-P REF: 985 080
  • Potassium 50 : 40-1000 mg/kg K REF: 985 045

Technical Data

Type: LED photometer with 3 interference filters
Wavelengths: 365 nm, 450 nm, 660 nm
Wavelength accuracy: ± 2 nm, bandwidth at half transmission 10–12 nm
Measuring modes: Pre-programmed tests
Cuvette holder: Tubes 16 mm OD
Memory: 50 results
Display: Backlit graphic display, result with unit
Operation: Self-explanatory menu guidance, plastic foil keypad
test selection via parameter lists
Power supply: 3 AA batteries, rechargeable batteries, USB interface; optional internal accu-pack
Housing: Water proof, IP 68 certified
Dimensions: 170 x 95 x 68 mm
